KISS ESC 2-5S 25A (40A limit)
The KISS ESC 2‑5S 25A (40 A limit) is a high‑performance brushless motor controller for race multicopters, featuring a 32‑bit ARM Cortex‑M4 processor, extensive telemetry, overcurrent and temperature protection, and advanced DShot support.
- Price
- €22.90indicative
- Origin
- Collected automatically
- Source
- Manufacturer page (flyduino.net) +1 more
- Retrieved
- 25 Sept 2026
- Last checked
- 25 Sept 2026
- Report
- Report an error or request removal
Designed to power strong motors on competitive quadcopters, this ESC offers 25 A continuous output with an active limit of 40 A for safety. It incorporates a sinHybrid mode for smoother operation and delivers precise throttle control via 2000‑step DShot resolution. The unit supports a wide range of command protocols and provides robust protection against voltage extremes.
Power
- Operating voltage
- 6–24 V
Current
- Maximum continuous current
- 25 A
- Instantaneous maximum current (limit)
- 40 A
Performance
- Maximum RPM / ERPM
- 500,000 ERPM
Hardware
- Processor
- 32‑bit ARM Cortex‑M4 @ 80 MHz
Telemetry
- Telemetry capability
- Voltage, current, temperature, RPM
Control
- DShot resolution
- 2000 steps (2400 mode)
- DShot range supported
- 100–2400, OneShot42/125, PWM 25–500 Hz
Features
- SinHybrid mode
- Yes
Protection
- Overcurrent protection
- Active limit at 40 A
- Overtemperature protection
- Reduces power above 100 °C
- Input/Output voltage protection
- ±30 V limits, 3.3/5 V compatible
Power Supply
- Gate driver capacitors
- 396 µF 25 V ceramic (onboard)
Size
- Physical dimensions
- 12.5 × 26 mm
Additional specifications are shown as published by the source, without unit conversion. Spotted an error? Report it to us, tell the manufacturer or claim this listing.
- Software & SDKs
- Firmware v121aFlashloader sinHybrid-de/enSound Editor V1.0c
