Stinger Vision FPV
A ready‑to‑fly multirotor FPV drone featuring U.S.-made autonomous compute, GPS-denied navigation and encrypted digital video for defense and enterprise missions.
- Price
- US$3,399.99indicative
- Availability
- In production
- Origin
- Collected automatically
- Source
- Manufacturer page (modalai.com) +1 more
- Retrieved
- 25 Sept 2026
- Last checked
- 25 Sept 2026
- Report
- Report an error or request removal
The Stinger Vision FPV is a compact multirotor equipped with VOXL 2 Mini autonomy hardware powered by a Qualcomm QRB5165 processor. It delivers AI‑assisted flight modes, dual AR0144 computer‑vision cameras and an optional 4‑MP EO sensor, along with encrypted HD video via MVX. Designed for Blue UAS Cleared Select and NDAA compliance, it can be deployed in under a minute when batteries are charged.
General
- Propulsion
- Electric
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 80%
Collected automatically from the source; not reviewed yet.
Performance
- Endurance
- 12min
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 80%
Collected automatically from the source; not reviewed yet.
Physical
- MTOW
- 0.3kg
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 85%
Collected automatically from the source; not reviewed yet.
- Empty weight
- 0.4kg
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 80%
Collected automatically from the source; not reviewed yet.
- Weight
- 0.6kg
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 80%
Collected automatically from the source; not reviewed yet.
- Dimensions
- 198mm x 228mm x 85mm
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
Payload
- Payload
- 0.5kg
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 85%
Collected automatically from the source; not reviewed yet.
Communications
- Datalink range
- 11km
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 80%
Collected automatically from the source; not reviewed yet.
- Interfaces
- WiFi, Microhard, 5G, ELRS
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 85%
Collected automatically from the source; not reviewed yet.
Power
- Battery / fuel
- Upgrade Energy 3000 mAh 4S 14.4 V P30B Li‑Ion, XT60
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
Software/autonomy
- Ground control software
- VOXL SDK 1.4.5
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
Compliance/certification
- NDAA compliant
- Yes
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- High · 90%
Collected automatically from the source; not reviewed yet.
- Blue UAS
- Framework
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- High · 90%
Collected automatically from the source; not reviewed yet.
- Export classification
- EAR controlled
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
- Country of origin
- USA
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 85%
Collected automatically from the source; not reviewed yet.
- Manufactured in
- US
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
- Certifications
- NDAA compliant
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
- Export control notes / ECCN
- 6A993.A
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- High · 90%
Collected automatically from the source; not reviewed yet.
Product Specifications
- Specification
- Details
- Flight Control
- PX4 on VOXL 2 Mini, accelerated by the onboard DSP
- Video Transmitter (MVX)
- ModalAI M0185-1 VTX, tunable 2.412-2.484 GHz and 5.16-5.885 GHz
Camera and Thermal Configurations
- Config
- Sensors
- C35
- Dual ModalAI M0166 AR0144 computer-vision cameras plus the ModalAI M0186 IMX664 EO camera. Sold as "EO Only".
- C34
- The C35 camera set plus the Boson+ 640 thermal payload. Sold as "EO and Boson+ 640".
- X8
- FLIR Lepton 3.5 downward thermal, for night-time position hold
- X0
- No downward thermal (DIY EO Only kit)
- M26
- ModalAI MVX (M0185-1 VTX)
- T8
- ModalAI ELRS 915 MHz
What's Included
- Kit Config
- Description
- -K0
- Drone only
- -K1
- Drone and battery
- -K2
- Drone with battery and controller (Zorro Blue)
- -K4
- Drone with battery, controller and VRX (with HDMI output)
- -K5
- Drone with battery, controller and goggles with integrated VRX
- -K6
- The -K5 kit with a carrying case
- -DIY
- Self-assembly, drone only
Compatible Products
- Product
- Compatible?
- MVX VRX Ground Unit
- ✅ required to receive the FPV video stream
- Zorro Blue Controller (MRC-Z0001-1)
- ✅ included in -K2 and above
- Third-party 915 MHz ELRS 3.5 transmitters
- ✅
- Upgrade Energy 3000 mAh 4S P30B Li-Ion, XT60
- ✅ recommended battery
- 4S1P to 6S1P packs with XT60
- ✅
- HDMI-based FPV goggles and displays
- ✅ via VRX HDMI output
- Analog FPV goggles
- ❌ MVX is a digital, encrypted link
- Starling 2 / Starling 2 Max replacement parts
- ❌ different airframe
Export Information
- Item
- Value
- ECCN
- 6A993.a (due to inclusion of FLIR Lepton)
- Harmonized Tariff Schedule (HTS) Code
- 8806.22.0000
- Radio Frequencies Used
- MVX video: 2.412-2.484 GHz and 5.160-5.885 GHzR/C: 915 MHz ELRS (configurable to 868 MHz)
- RoHS Compliant
- Yes
MVX Digital FPV Streaming (U.S.-Made)
- Low latency
- under 35 ms glass-to-glass with low-latency settings, 45 ms typical
- Dual band
- 2.412-2.484 GHz and 5.160-5.885 GHz
General
- Integrated Qualcomm QRB5165 chipset
- 8 cores up to 3.091 GHz, 8GB LPDDR5
- Price
- from $3,399.99
- Compute
- QRB5165
- Image Sensors
- Dual AR0144 fisheye CV image sensor, IMX664 color image sensor, (Optional) 640x480 VGA Boson®+ Thermal
- Takeoff Weight
- 575g
- Propellers
- GemFan D90 3.5", 5-blade
- Motors
- ModalAI Custom 2204, 2450 kV
- Frame
- Custom
- ESC
- ModalAI M0129-63 Mini 4-in-1
- Computing
- VOXL 2 Mini (Qualcomm QRB5165, 8 cores up to 3.091 GHz, 8 GB LPDDR5)
- Flight Controller
- PX4 on VOXL 2 Mini
- Onboard Sensors
- Dual TDK ICM‑42688 IMU and ICP‑10100 barometer
- Video Transmitter
- ModalAI M0185‑1 VTX, tunable 2.412–2.484 GHz and 5.16–5.885 GHz
- R/C Receiver
- ModalAI M0184 Gemini ELRS 915 MHz (configurable to 868 MHz)
- Video Encryption
- 256‑bit AES encryption
- Datalink Type
- Digital HD video, dual band 2.412–2.484 GHz & 5.160–5.885 GHz, tested up to 11 km
- Perception Cameras
- Dual AR0144 fisheye computer‑vision cameras; single IMX664 EO color sensor (4MP low‑light IR‑sensitive); optional Boson+ thermal 640×480 VGA
- Autonomy Features
- AI‑assisted flight modes, GPS‑denied navigation via Visual Inertial Odometry
Values are normalised to SI-style units. Open a value's source marker for provenance and confidence. Additional specifications are shown as published by the source, without unit conversion. Spotted an error? Report it to us, tell the manufacturer or claim this listing.
- Software & SDKs
- VOXL SDK
