Alta X Gen2
A heavy‑lift multirotor drone designed for industrial missions, delivering up to 15.9 kg of payload and 17–40 minutes of flight time.
- Price
- US$39,650indicative
- Origin
- Collected automatically
- Source
- Manufacturer page (freeflysystems.com) +1 more
- Retrieved
- 25 Sept 2026
- Last checked
- 25 Sept 2026
- Report
- Report an error or request removal
The Alta X Gen2 is a rugged, American‑made multirotor platform built for demanding payloads and long endurance. It supports dual Ublox F9P GPS modules, an LTE connection, and a modular payload bay with smart dovetail integration. The aircraft folds to half its size, features vibration‑reduced ActiveBlade design, and includes dual smart batteries for reliable power management.
Performance
- Endurance
- 40min
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 80%
Collected automatically from the source; not reviewed yet.
Physical
- MTOW
- 34.9kg
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 80%
Collected automatically from the source; not reviewed yet.
- Weight
- 34.9kg
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 80%
Collected automatically from the source; not reviewed yet.
Payload
- Payload
- 15.9kg
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 80%
Collected automatically from the source; not reviewed yet.
Communications
- Interfaces
- Wifi, USB C, LTE (North America) Wifi, USB C, LTE (North America)
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 85%
Collected automatically from the source; not reviewed yet.
Navigation
- GNSS
- Dual Ublox F9P GPS (L1/L2)
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
Environment
- IP rating
- IP43
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
Power
- Battery / fuel
- 12S LiPo
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
Compliance/certification
- NDAA compliant
- Yes
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- High · 90%
Collected automatically from the source; not reviewed yet.
- Country of origin
- US
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
- Manufactured in
- US
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- Medium · 75%
Collected automatically from the source; not reviewed yet.
- Certifications
- IP43, NDAA compliant
Source
- Source
- Manufacturer page
- Retrieved
- 25 Sept 2026
- Last reviewed
- 25 Sept 2026
- Confidence
- High · 90%
Collected automatically from the source; not reviewed yet.
Flight time
- Flight Time - No Payload
- 40:02 mins 40:02 mins
- Flight Time - Max Payload
- 17:00 mins 17:00 mins
Weight
- Maximum Gross for Takeoff
- 34.9 kg 76.9 lbs
Powerplant
- Number of Motors
- 4 4
- Motor Max Continuous Output
- 100A 100A
- Motor Max Instantaneous Peak Output
- 130A (>3s) 130A (>3s)
- Equivalent Kv
- 115 RPM / V 115 RPM / V
Dimensions
- Unfolded Diameter (no props)
- 1570 mm 61.8 in
- Unfolded Diameter (with props)
- 2273 mm 89.5 in
- Folded Diameter (with props)
- 877 mm 34.5 in
- Height from chassis underside to ground (medium leg length landing gear)
- 450 mm 17.7 in
- Height from chassis underside to ground (long leg length landing gear)
- 580 mm 22.8 in
General
- Material
- Carbon Fiber Reinforced Nylon Carbon Fiber Reinforced Nylon
- Propeller Type
- Folding - 840 x 230 mm (33 x 9in) Folding - 840 x 230 mm (33 x 9in)
- Cells
- 12S 12S
- Nominal Battery Voltage
- 44.4V 44.4V
- Peak Battery Voltage
- 50.4V 50.4V
- Battery Connectors
- AS150U Anti-Spark AS150U Anti-Spark
- Flight Controller Hardware
- Freefly Custom Designed Skynode Freefly Custom Designed Skynode
- Flight Controller Software
- Auterion Enterprise PX4 (custom for Alta X) Auterion Enterprise PX4 (custom for Alta X)
- Mission Control Software
- Auterion Mission Control Auterion Mission Control
- Online Fleet Management
- Auterion Suite Auterion Suite
- Onboard Modules
- Cortex-A53 Computer LTE Cortex-A53 Computer LTE
- Supported Radios
- Herelink, Doodle Herelink, Doodle
- Supported GNSS
- L1/L2 bands for GPS, GLONASS, Beidou and Galileo L1/L2 bands for GPS, GLONASS, Beidou and Galileo
- Flight Modes
- Manual, Altitude Hold, Position Hold, Return, Autonomous Mission Manual, Altitude Hold, Position Hold, Return, Autonomous Mission
- Operating Temperature
- -20C to +50C -20C to +50C
- ALTA X GEN2
- : LR1 || VOYAGER AUW:: 48LBS
- Operating temperature min
- -20°C
- Operating temperature max
- 50°C
- Datalink
- LTE, Wi‑Fi
- Dual smart batteries
- Yes
Media
- Everest Base Camp
- Alta X Gen2 delivers emergency supplies at altitude Watch video
Values are normalised to SI-style units. Open a value's source marker for provenance and confidence. Additional specifications are shown as published by the source, without unit conversion. Spotted an error? Report it to us, tell the manufacturer or claim this listing.
- Software & SDKs
- Auterion Mission ControlAuterion Suite
Ask Freefly Systems about Alta X Gen2
